Baldor – CESSWDM3615T-5
Stainless Steel, 3Ph, TE, C-Face, Foot Mounted
5HP, 1800RPM, 184TC, TEFC, 575V, Washdown
Catalog Number: CESSWDM3615T-5
Spec Number: 36L738R058G2

Enclosure: TEFC
Frame: 184TC
Frame Material: Stainless Steel
Frequency: 60.0 Hz
Motor Letter Type: Three Phase
Output @ Frequency: 5.0 HP @ 60 Hz
Phase(s): 3
Synchronous Speed @ Frequency: 1800 RPM @ 60 Hz
Voltage @ Frequency: 575.0 V @ 60 Hz
Agency Approvals: UR, CSA
Ambient Temperature: 40 °C
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Current @ Voltage: 5.2 A @ 575.0 V
Design Code: A
Duty Rating: CONT
Efficiency @ 100% Load: 89.5 %
High Voltage Full Load Current: 5.2A
Front Face Code: Standard
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: J
Lifting Lugs: No Lifting Lugs
Locked Bearing Indicator: Locked Bearing
Motor Lead Quantity/Wire Size: 3 @ 16 AWG
Motor Type: 3646M
Mounting Arrangement: F1
Number of Poles: 4
Overall Length: 18.32 IN
Power Factor: 81
Product Family: Wash Down All Stainless Steel
Pulley Face Code: C-Face
Service Factor: 1.15
Shaft Diameter: 1.125 IN
Shaft Rotation: Reversible
Speed: 1750 rpm
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
