3787 – General Electric
Split Cap, Auto O/L,
1/2HP, 48 Fr, 115V, 1075RPM, 60Hz, 1Ph,

Output (HP): 1/2
Output (kW): 0.245
Type: Split Cap
Part Num.: 3787
Voltage: 115V
Current: 7.6A
Phase(s): Single
Frequency: 60Hz
Speed (RPM): 1075
Num. of Speeds: 4
Dir. of Rotation: Reversible
Frame Material: Rolled Steel
Enclosure: OAO
Body Frame: 48
Mounting: Flex Mount (3x)
Agency Approvals: CSA, UL
Insulation Class: F

Use with: Fan Coils, Blowers, Etc.

Cross Reference:
FML1056, D1732, 3787, X036, 754, R42036, R42219,
