Baldor – M3542
General Purpose
3/4 HP, 1725RPM, 56Fr, TEFC, 230~460V,
Catalog Number: M3542
Spec Number: 34A61-883

Baldor’s extensive line of General Purpose motors are available in a wide variety of construction enclosures from industrial steel band open designs to harsh applications requiring totally enclosed cast iron designs in both single and three phase.

Enclosure: TEFC
Frame: 56
Frame Material: Steel
Frequency: 60.0 Hz
Motor Letter Type: Three Phase
Output @ Frequency: 0.750 HP @ 60 Hz
Phase(s): 3
Synchronous Speed @ Frequency: 1800 RPM @ 60 Hz
Voltage @ Frequency 208.0 V @ 60 Hz | 230.0 V @ 60 Hz | 460.0 V @ 60 Hz
Agency Approvals: UR, CSA
Ambient Temperature: 40 °C
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Current @ Voltage: 1.50 A @ 460.0 V | 3.0 A @ 230.0 V | 3.2 A @ 208.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Efficiency @ 100% Load: 75.5 %
High Voltage Full Load Current: 1.5 A
Front Face Code: Standard
Insulation Class: B
Inverter Code: Not Inverter
KVA Code: M
Lifting Lugs: No Lifting Lugs
Motor Lead Quantity/Wire Size: 9 @ 18 AWG
Motor Type: 3420M
Mounting Arrangement: F1
Number of Poles: 4
Overall Length: 11.35 IN
Power Factor: 64
Product Family: General Purpose
RoHS Status: ROHS COMPLIANT
Service Factor: 1.25
Shaft Diameter: 0.625 IN
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed: 1725 rpm
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
