H508 – CENTURY
3/4HP, 3450/2850RPM, 208-230/460V, ODP, L56C
Catalog Number: H508

Output HP: 3/4 Hp
Output KW: 0.56 kW
Frequency: 60/50 Hz
Voltage: 208-230/460 V
Current: SF 3.4-3.4/1.7 A
Speed: 3450/2850 rpm
Service Factor: 1.5
Phase: 3
Duty: Continuous
Insulation Class: B
Frame: L56C
Enclosure: Drip Proof
Thermal Protection: No Protection
Max Ambient Temperature: 40 °C
UL: Recognized
CSA: Y
CE: N
Number of Speeds: 1

Electrical Type: Polyphase, Induction Type, Single Or Dual Voltage
Starting Method: Across The Line
Poles: 2
Rotation: Reversible Counter-clockwise
Mounting: Round
Drive End Bearing: Ball
Opp Drive End Bearing: Ball
Frame Material: Rolled Steel
Shaft Type: Keyed
Overall Length: 11.29 in
Frame Length: 6.25 in
Shaft Diameter: 0.625 in
Shaft Extension: 2.07 in
