Catalog Number: EM3211T
Enclosure: OPSB
Frame: 182T
Frame Material: Steel
Frequency: 60.00 Hz
Motor Letter Type: Three Phase
Output @ Frequency: 3.000 HP @ 60 Hz
Phase(s): 3
Synchronous Speed @ Frequency: 1800 RPM @ 60 Hz
Voltage @ Frequency: 208.0 V @ 60 Hz / 230.0 V @ 60 Hz / 460.0 V @ 60 Hz
Agency Approvals: CSA, EEV, UR
Ambient Temperature: 40 °C
Base Indicator: Rigid
Bearing Grease Type: Polyrex EM (-20F +300F)
Blower: None
Current @ Voltage: 8.500 A @ 208.0 V / 8.400 A @ 230.0 V / 4.200 A @ 460.0 V
Design Code: B
Drip Cover: No Drip Cover
Duty Rating: CONT
Efficiency @ 100% Load: 89.5 %
Electrically Isolated Bearing: Not Electrically Isolated
Feedback Device: NO FEEDBACK
High Voltage Full Load: 4.2 A
Front Face Code: Standard
Front Shaft Indicator: None
Heater Indicator: No Heater
Insulation Class: F
Inverter Code: Inverter Ready
KVA Code: K
Lifting Lugs: Standard Lifting Lugs
Locked Bearing Indicator: No Locked Bearing
Motor Lead Quantity/Wire Size: 9 @ 16 AWG
Motor Type: 3630M
Mounting Arrangement: F1
Number of Poles: 4
Overall Length: 15.00 IN
Power Factor: 74
Product Family: General Purpose
Pulley Face Code: Standard
Pulley Shaft Indicator: Standard
Rodent Screen: None
Service Factor: 1.15
Shaft Diameter: 1.125 IN
Shaft Ground Indicator: No Shaft Grounding
Shaft Rotation: Reversible
Shaft Slinger Indicator: No Slinger
Speed: 1765 rpm
Speed Code: Single Speed
Motor Standards: NEMA
Starting Method: Direct on line
