1/6HP 1075 RPM 115V REV 1/2 48Y BAL
Availability: 2 in stock
$258.96
Availability: 2 in stock
UH-9034 – ALLTEMP/ROTOM
1/6HP, 115V, 2.38A, 1075RPM, 48Y, AOA, PSC,
Catalog #: UHM16B
Capacitor: 5uF/370V
Output (HP): 1/6
Output (kW): 0.12
Enclosure: Totally Enclosed Air Over (TEAO)
Rotation: Reversible
Speed (RPM): 1075
Frame: 5.6/48Y
Phase(s): Single
Voltage (V): 115
Current (A): 2.4
Insulation Class: B
Cross-Reference:
Emerson/Lennox: K48HXFGP-3814
| Manufacturer: | ROTOM/ALLTEMP |
|---|---|
| Agency Approval: | UL |
| HP: | 1/6 |
| Voltage: | 115.0 |
| Current: | 2.5 |
| RPM: | 1100 |
| Frame: | 48Y |
| Enclosure: | TEAO |
| Frequency: | 60.0 |
| Model/Family/Series/Purpose | Exhaust, Ventilation, HVAC |
| Frame Material: | Rolled Steel |
| Insulation Class: | B |
| Number of Speeds: | Single |
| Number of Poles: | 6 |
| Service Factor: | 1.0 |
| Output (kW): | 0.12 |
| Direction of Rotation: | Reversible |
| VFD/Inverter Ready: | No |
| Duty: | CONT |
| Phase(s): | Single |
| Shaft Diameter: | 5/8 |
| Shaft Length: | 3.50 |
| Weight: | 12.00 |
| Mounting Arrangement: | Bracket, Stud |
| Starting Methods: | DOL |
| Motor Standards: | NEMA |
| Leads (Qty, Size): | 2x |
| Front Face Code: | Resilient Mount for Braket |
| AC/DC | AC |
