D126 – FASCO – 3.3″ Dia. 1/40HP, 1 SPD.

3.30″ DIA. 1/40 HP 1 SPD.

Availability: 2 in stock

$166.78

Availability: 2 in stock

D126 – FASCO – 3.3″ Dia. 1/40HP, 1 SPD.

D126 – Fasco
Fan and Blower Motor,
1/40HP, 1Ph, 60Hz, 115V, 1500RPM, 1 Spd, 3.3″ Dia., OAO
Part #:D126
Catalog #:D126

*Note: Sleeve Bearings
Output HP: 1/40 Hp
Output KW: 0.02 kW
Voltage: 115 V
Phase(s): 1
Speed: 1500 rpm
Service Factor: 1
Frame: 3.3
Enclosure: Open Air Over
Thermal Protection: Thermally Protected
Ambient Temperature: 40 °C
Frequency: 60 Hz
Current: 1.10 A
Duty: Air Over
Insulation Class: B
Agency Recognition: UL, CSA
Number of Speeds: 1
Electrical Type: Shaded Pole
Starting Method: Across The Line
Poles: 4
Rotation: Clockwise Shaft End
Mounting: Extended Studs
Drive End Bearing: Sleeve
Opp Drive End Bearing: Sleeve
Frame Material: Steel
Shaft Type: Flat
Overall Length: 5.08 in
Frame Length: 2.24 in
Shaft Diameter: 0.313 in
Shaft Extension: 2.30 in
Weight: 2.80 LB
Length: 8.00 IN
Width: 3.38 IN
Height: 3.38 IN

Replaces: JA2C554N – [splice original connector, cut shaft and studs as required]

Weight 2.8 lbs
Manufacturer:

Fasco

Agency Approval:

UL, CSA

HP:

1/40

Voltage:

115

Current:

1.1

RPM:

1500

Frame:

3.3

Enclosure:

Open Air Over (OAO)

Frequency:

60Hz

Model/Family/Series/Purpose

General Purpose, Direct Drive Fan, Blower

Frame Material:

Rolled Steel

Insulation Class:

B

Number of Speeds:

Single

Number of Poles:

4

Service Factor:

1.0

Output (kW):

0.02

Direction of Rotation:

CW (SE)

DE Bearing:

Sleeve Bearing

ODE Bearing:

Sleeve Bearing

VFD/Inverter Ready:

No

Duty:

CONT.

Phase(s):

Single

Shaft Diameter:

0.313

Shaft Runout:

2.30

Length:

>8.0

Weight:

>3

Width:

>3.4

Height:

>3.4

Mounting Arrangement:

4x Studs

Starting Methods:

DOL

Motor Standards:

NEMA

Front Face Code:

Standard, 4x Stud

AC/DC

AC
