BF2N.75-5C – 0.75HP, 3600RPM, 575V, 56C Fr, TEFC

0.75HP, 3600RPM, 575V, 56C Fr, TEFC

Out of stock

SKU BF2N.75-5C Category Tags , , , , ,

$280.67

Out of stock

BF2N.75-5C – 0.75HP, 3600RPM, 575V, 56C Fr, TEFC

SKU BF2N.75-5C Category Tags , , , , ,

Brook Crompton – BF2N.75-5C
3/4HP, 3600RPM, 56C, TEFC, 575V
General Purpose
Catalog Number: BF2N.75-5C

HP: 3/4
RPM: 3600
Voltage: 575V
Frame: 56C
Phase(s): 3
Enclosure: TEFC
Material: Aluminum
Mounting: C-Face / Removable Base, C-Face / Rigid, C-Face / Round Body
Phase(s): 3
Nominal Efficiency: 74.0%
Frame
56C
Enclosure
TEFC
Mounting
C-Face / Removable Base, C-Face / Rigid, C-Face / Round Body
Approx. Weight: 17 Lbs
Frame Material: Aluminum
C-Dimension: 11.54″
Shaft Diameter: 0.625″
Shaft Length: 1.875″

Weight 23 lbs
Manufacturer:

Brook Crompton

Agency Approval:

CSA, UL

HP:

3/4

Voltage:

575.0V

RPM:

3600

Frame:

56C

Enclosure:

TEFC

Frequency:

60.0Hz

Model/Family/Series/Purpose

General Purpose

Frame Material:

Aluminium

Number of Speeds:

Single

Efficiency:

74.0%

Number of Poles:

2

Service Factor:

1.15

Output (kW):

0.52

Direction of Rotation:

Reversible

Duty:

CONT

Phase(s):

3

Shaft Diameter:

0.625"

Shaft Runout:

1.875"

Length:

11.54"

Weight:

18 Lbs

Mounting Arrangement:

F1

Starting Methods:

DOL

Motor Standards:

NEMA

Front Face Code:

Standard

AC/DC

AC
